multi axis CNC turning lathe machine with Sauter servo turret SY500/S500/SY300/S300 turning center

Item No.: SY300
sauter BMT55 (ER25) living tools, machining length 300mm, A2-5/A2-6 POSA spindle, 11KW spindle motor , Syntec 22TB controller, optional Fanuc 0i MF controller
  • lathemulti axis lathe
  • $67500.00
    / Pieces
    |
    1 Pieces(Min. Order)
    • controller:
      Syntec 22TB
      Fanuc 0i MF
    • spindle nose:
      A2-5
      A2-6
    • Max machining length:
      300mm
      500mm
    • Y axis:
      WITH
      WITHOUT
    Description Review
    Description



    multi axis CNC turning lathe machine with Sauter servo turret SY500/S500/SY300/S300 turning center

    Fanuc controller AVAILABLE!



    Parameter   SY500 S500 SY300 S300
    Capacity Max.   material diameter thru main spindle  ¢55   mm ¢45mm ¢55/¢45mm ¢55/¢45mm
    Swing over bed ¢500mm ¢500mm ¢500mm ¢500mm
    Max. machining diameter ¢300   mm ¢300   mm ¢500mm ¢500mm
    Max. length of machining 500   mm 500   mm 300 mm 300 mm
    Max. travel of x-axis 260   mm 260mm 450mm 450mm
    Max. travel of z-axis 550   mm 550 mm 300mm 300mm
    Max. travel of Y-axis 100   mm / 100mm /
    Rapid speed (x-axis/z-axis) 30   m/min 30 m/min 30 m/min 30 m/min
    Reposition accuracy 0.005   mm 0.005 mm 0.005 mm 0.005 mm
    Motor Main   electric spindle 15KW 15KW 15KW/11KW 15KW/11KW
    Spindle speed 3000   rpm 3000 rpm 3000/4500rpm 3000/4500rpm
    X/Y/Z-axis servo motor 1800   W 1800 W 1800 W 1800 W
    Tools Servo   turret 12T 12T 12T 12T
    Living tool holder size ER32 ER32 ER32 ER32
    Other Total   power 25KW 25KW 25KW 25KW
    Size( L x W x H ) 2986*1950*2253 2986*1950*2253 2748*2590*2300 2748*2590*2300
    N.W. 5000   KGS 5000   KGS 3500KGS 3500KGS



    product-JSWAY-img

    product-4 axis lathe-JSWAY-img

    product-JSWAY-img

    product-JSWAY-4 axis CNC milling lathe machine with Sauter servo turret SY500S500SY300S300 machining

    product-4 axis CNC milling lathe machine with Sauter servo turret SY500S500SY300S300 machining cente

    product-JSWAY-4 axis lathe-img

    product-4 axis CNC milling lathe machine with Sauter servo turret SY500S500SY300S300 machining cente-1

    Detailed Images


    product-JSWAY-img-1

    Production Flow

    product-4 axis lathe-JSWAY-img-1

    Related Products

      product-JSWAY-img-1

    After-Sales Service

    product-JSWAY-4 axis CNC milling lathe machine with Sauter servo turret SY500S500SY300S300 machining-1

    1. We are a manufacturer of slant bed cnc lathe machine  for 10 years ,Technology in the industry is come
    out in front.

    2. Our supply ability is sufficient to guarantee the customers demand.

    3. Where you can buy all the Equipments for your market ,at the mean time the customers can enjoy the
    long-term technical advisory services in our company.

    4. Our products can be OEM ,meet your special needs.

    5. Our Advantages and quick delivery, Competitive price ,high quality and long term service to out customers.

    6. There is a long-term cooperation with the shipping company, can make the goods more quickly and
    efficiently so that can delivered safely to the designated place as guest.

    7. We will provide best after sale service for the guests which try my best to meet the requirements of
     guests.

    Certifications

    product-4 axis CNC milling lathe machine with Sauter servo turret SY500S500SY300S300 machining cente-1





    Company Information

    product-JSWAY-img-2product-4 axis lathe-JSWAY-img-2product-JSWAY-img-2

    FAQ

      product-JSWAY-4 axis CNC milling lathe machine with Sauter servo turret SY500S500SY300S300 machining-2

    1. What accuracy can processed work piece reach?

    Machining accuracy is very complicated for it can be affected by people, machine, methods, material
    and environment, and machine itself is just one of them; besides, accuracy could mean flatness,
    verticality, roundness, alignment or position degrees and so on, it’s hard to make it clear in general
    concept. Thus pls provide us your machining drawing, we are very glad to design a specific process
    solution for you and recommend you a proper cnc machine model.

    2. You can hold much lathe knife? There are several options?

    Slant bed lathe usually can install 5-7 tools, turret lathe can install 8/10 tools on turret,2-3 tools
    on table.

    3. How to choose the best fit for your machine?

    If you have special request for the machine tool configuration,And the budget is limited,We can also
    according to your need to change the configuration. Thus pls provide us your machining drawing,
    we are very glad to design a specific process solution for you and recommend you a proper cnc
    machine model.

    4. About OEM

    Our products can be OEM ,meet your special needs. We have a very rich experience and strong
    machine tool research and development capability. We are very willing to offer you customized
    highly-efficient equipment as long as you have certain amount of needs.

    5.About Shipping

    There is a long-term cooperation with the shipping company, can make the goods more quickly and
    efficiently so that can delivered safely to the designated place as guest.

    6. About supply ability

    Our supply ability is sufficient to guarantee the customers demand. Where you can buy all the
    Equipments for your market ,at the mean time the customers can enjoy the long-term technical
    advisory services in our company.

    7. About after sale service

    We will provide best after sale service for the guests which try my best to meet the requirements
    of guests.Our Advantages and quick delivery, Competitive price ,high quality and long term
    service to out customers.


    Welcome to contact us if need any more information.
